October 24, 2026 Vivian Vu

Moving a Solaris and Karma XPU Scene to a Render Server in 2026: Save Paths, Relative References, Flattening and husk

Quick answerMake a Solaris scene render anywhere
Checked Nov 2026

A Solaris scene renders on another machine when every layer, cache and texture it references can be found there. Give layers save paths under $HIP, let the USD ROP write relative references, keep everything in one project folder, then render with husk or the USD Render ROP.

  • Save paths: set them as absolute paths with $HIP; the default output processor turns them into relative references.
  • Textures: only attributes of type asset are converted; string paths stay absolute.
  • Flattening: flatten layers, not the whole stage, or the file becomes enormous.
  • husk: renders a saved USD file from the command line with frame range, settings and output options.

A Solaris scene is a set of USD layers that point to other layers, caches and textures by file path. It renders on another machine only when every one of those paths can be found there. The fix is a consistent layout: layers with save paths under $HIP, relative references written by the USD ROP, and one project folder that moves as a unit.

This guide covers how save paths and output processors work, which texture paths need care, when to flatten, and how to render the saved USD with husk. For moving large caches, see our guide to uploading Houdini caches to a render farm.

Checked against the SideFX documentation for Writing out USD and husk, and SideFX staff answers on the Solaris forum, November 2026.

1. Why does a Solaris scene break on another machine?

Because USD files reference other files by path. If a layer, payload or texture points to a folder that exists only on your workstation, the render server cannot find it, and geometry or textures go missing. Layers authored in LOPs without a save path are another cause: Houdini writes them as temporary files instead of files you control.

A SideFX forum user summed up the second problem when helping another artist: most of their own issues came from not setting save paths on the layers authored inside Solaris (forum topic 78476).

2. How do save paths and relative references work in Solaris?

The USD ROP’s Output file sets the top-level file, and every layer with a save path is written to its own file. SideFX recommends absolute save paths, often using $HIP. During the save, the default output processor turns them into relative references between the layer files, so you can move all of them together to another location.

SideFX staff add one rule that explains most broken paths: a relative path in a USD file is always relative to the folder containing the USD file that does the referencing (forum topic 76401). For textures, the USD ROP converts paths only when the attribute or primvar has the data type asset, not string (forum topic 84246).

PortableChecklist by data type

What to check so a Solaris scene moves cleanly

Each kind of file the stage references, and how to keep its path working on another machine.

DataWhere the path is setHow to keep it portable
Authored LOP layersConfigure Layer LOP, SOP Import, SOP CreateSet a save path under $HIP
Top-level USDUSD ROP Output fileWrite it inside the project folder
References and sublayersReference and Sublayer LOPsLet the output processor make them relative
TexturesMaterial and primvar attributesUse asset-type attributes so the path is converted
Per-frame dataFiles with $F in the nameKeep frame files beside the layer that uses them
Takeaway: if every path lives under one project folder and is written relative, the folder can move to any machine.

3. Should you flatten a Solaris scene before rendering it elsewhere?

Flatten layers, not the stage. A SideFX staff member explains that the USD Render ROP does the equivalent of flattening all layers, while flattening the whole stage pulls all referenced data into one file and makes it enormous (forum topic 74412). Keep large caches as separate referenced files, with relative paths, and upload them once.

Time-dependent data needs a decision too. With Flush Data After Each Frame on and $F in the file name, the USD ROP writes one file per frame; with it off, frames are combined in memory, which SideFX notes can use a lot of memory.

iRender
Moving a Solaris scene to a render server: the references move with the folder
SOLARIS / USD
On your workstationD:/projects/shot/shot.usdageo.usd./usd/mtl.usd./usd/pyro.$F4.vdb./cache/uploadsame folder structureOn the render serverC:/Users/you/shot/shot.usdageo.usd./usd/mtl.usd./usd/pyro.$F4.vdb./cache/Relative references are resolved from the folder of the file that references them, so the whole folder can move
Relative referenceProject folder
Folder names are an example

How to read the figure. The left side is the project on your workstation; the right side is the same folder on the server. As long as the structure is unchanged, every relative reference still resolves.

4. How do you render the saved USD with husk?

husk is SideFX’s command-line utility for rendering a USD file with Karma or another Hydra renderer. The basic form is husk [options] usd_file -o image_file. Use -f for the start frame, -n for the number of frames, -i for the increment, -s to pick a RenderSettings prim, and $F4 in the output name for four-digit frame numbers.

husk checklist (copy or follow line by line):

Render a Solaris shot with husk
Example
husk -f 1001 -n 120 -o render/shot.$F4.exr shot.usd → 120 frames from 1001
Options
-f → start frame
-n → number of frames
-i → frame increment
-s /Render/rendersettings → pick a RenderSettings prim
-V 3 → more log detail
Before a long run
Render one frame → check paths and AOVs
–karma-percent-of-samples → partial render for checkpoints

Step 1: Write the USD

On the USD ROP, set the Output file inside the project folder and keep the default relative-path output processor on. Check that every authored layer has a save path.

Step 2: Test the folder in a new location

Copy the project folder to a different path on your own machine and open the top-level USD there. Anything that breaks here will also break on the server.

Step 3: Upload and render one frame

Upload the whole folder with its structure, then render a single frame with husk. Check that geometry, textures and AOVs are all present.

Step 4: Render the range

Run husk with -f and -n for the full frame range and $F4 in the output name, or render from the USD Render ROP inside Houdini.

iRender
Moving a Solaris scene to a render server: four steps
D1
USD ROPOutput file$HIP/usd/shot.usda1Referencesrelative pathsCopy of the project at a new pathE:/test/shot/ renders the same2Server: one framehusk -f 1001 -n 1 usd/shot.usda -o render/shot.$F4.exr3Server: full rangehusk -f 1001 -n 100 usd/shot.usda -o render/shot.$F4.exr4
Step to follow
Mockup based on SideFX docs; paths are examples

How to read the figure. The badges follow Steps 1 to 4 above. Badge 1 is the USD ROP output inside the project, with relative references. Badge 2 is the test copy of the project at a new path on your own machine. Badges 3 and 4 are the husk commands on the server: one frame first with -n 1, then the full range. Paths and frame numbers are examples.

iRender
Flatten layers, not the stage
SOLARIS / USD
Layers kept separateshot.usdageo.usdmtl.usdlights.usdpyro cachereferenced, uploaded oncesmall layers, big caches referenced by relative paththe USD Render ROP flattens layers for you at render timeWhole stage flattenedshot_flat.usdevery referenced cache copied into one fileenormous to write and to upload (SideFX staff, forum)
PortableAvoid
Block sizes are illustrative

How to read the figure. The figure shows the most common size mistake. Most problems come from a path that was absolute or pointed outside the project folder when the USD was written.

5. What changes when the render server is a whole machine you control?

On a machine you control, you can open the .hip file in Houdini, check the stage in Solaris and render from the USD Render ROP, exactly as on your workstation; husk becomes an option rather than the only route. The portability rules above still apply, because the files have moved to a new path.

A SaaS render farm renders submitted jobs with its own setup, which suits finished, self-contained scenes. An IaaS server is a whole machine you control: you install your Houdini build, use your own SideFX license, and fix a missing path yourself in the scene instead of resubmitting a job.

SaaS or IaaS render farm for a Solaris scene?

Both farm models can render a portable USD with husk. The difference is whether you can open the .hip or the top-level USD on the render machine and fix a broken reference there.

CompareNeutral guide

Rendering a Solaris and Karma XPU scene on a farm

How the two farm models fit depending on how portable the scene is.

Your situationSaaS render farmIaaS render farm (iRender)
The USD uses relative paths and passed the copy testA good fit: upload and the farm renders with huskWorks as well: upload the folder and render with husk
Some references may still point outside the projectUsually found in the job log after the renderOpen the scene on the server and fix the path in place
You need your own Houdini build, packages or HDAsCheck that the farm supports each oneInstall them yourself; they stay on your server between sessions
Rule of thumb: if the USD is portable and tested, a SaaS farm is the shorter path; if you still need to open and fix the scene, rent the whole machine.

A test workflow on an iRender server

iRender
Works 1:1 like your own PC: we keep your setup, you just get more GPUs
IaaS render farm
Your workstationscene.c4d · .blend · .hip1 GPUYour iRender serverscene.c4d · .blend · .hipup to 8 GPUs=same setupWindows or Ubuntu desktopYour software, in the version you chooseYour plugins and scriptsYour licensesYour scene and render settings, unchanged1 GPUGPU power: the only difference1, 2, 4 or 8 × RTX 5090 / 4090✓ Only the GPU count changes: open your scene and render the way you do at home
Same on both machinesTip: upload the full project folder with relative paths so textures are found

How to read the figure. The left box is your own workstation and the right box is the iRender server: the same desktop, Houdini version, plugins, licenses and render settings. The only difference is the GPU count, from 1 to 8 RTX 5090 or RTX 4090, so the scene renders on the server the way it does at home.

  1. Upload the project folder, with its structure unchanged, to iRender Drive before you start the server; uploading is free and does not use rental time.
  2. Start a server with RTX 5090 (32 GB) GPUs; for Karma XPU we recommend 4x RTX 5090. Install your Houdini build and sign in with your own SideFX license.
  3. Open the scene or the top-level USD and render one frame with the USD Render ROP or husk; check geometry, textures and AOVs.
  4. Render the frame range, then shut down; billing is per minute.

Frequently asked questions

1. Why are my textures missing when I render a Solaris scene on another computer?

The texture path probably stayed absolute. The USD ROP converts paths to relative only when the attribute or primvar has the data type asset, not string. Check the attribute type and keep textures inside the project folder.

2. What does the USD ROP output processor do?

By default it turns the absolute save paths of your layers into relative references between the layer files, so you can move all the files together to another location.

3. Are relative paths in USD relative to the .hip file?

No. SideFX staff explain that a relative path in a USD file is always relative to the folder containing the USD file that does the referencing.

4. Should I flatten the stage before sending it to a render farm?

Usually not. Flattening the whole stage pulls all referenced data into one very large file. The USD Render ROP flattens layers instead, which keeps files smaller.

5. What is husk in Houdini?

husk is SideFX’s command-line utility for rendering a USD file with Karma or another Hydra renderer. It takes options for frame range, render settings and output path.

6. How do I render a frame range with husk?

Use -f for the start frame and -n for the number of frames, for example husk -f 1001 -n 120 -o render/shot.$F4.exr shot.usd. Add -i to render every second or third frame.

7. Can I render a Solaris scene on iRender?

Yes. Upload the project folder, rent a server with RTX 5090 GPUs, install your Houdini build with your own SideFX license, and render from the USD Render ROP or husk. Billing is per minute.
